Automotive Vocational Training Equipment Engine Electronic Fuel Injection System Simulator

Car engine 1ZR-FE electronic fuel injection (efi) system

The equipment is based on Toyota Corolla 1ZR electronically controlled gasoline engine, and is made by anatomical process, fully demonstrating the composition and working process of automobile gasoline engine. It is suitable for the teaching needs of engine structure theory and maintenance training in middle and higher vocational and technical colleges, general education colleges and training institutions.

Main components: Anatomically processed engine, geared motor, geared motor controller, movable stand, stand power main switch, universal caster with locking, etc.

• Detailed Anatomy: Use the original engine for cross-section processing, fully displaying the crankshaft connecting rod mechanism, valve train, lubrication mechanism, cooling system, and intake/exhaust systems.
• Low-Speed Operation: Driven by a gear motor to demonstrate internal mechanical movements, including piston movement and valve timing, at observable speeds.
• Visual Clarity: Different colors distinguish gas, oil, and water pathways. All surfaces are treated with phosphating and baking paint for durability and brightness.
• CNC Precision: High-precision wire cutting ensures flat surfaces on the cylinder block, valve cover, and cylinder head for clear internal observation.
• Integrated Lighting: Uses synchronized colored lights to indicate the four-stroke cycle principle clearly.
• Durable Construction: Built with international standard aluminum alloy profiles—lightweight, corrosion-resistant, and high-strength.
