Versatile RGB CCT Dimmable LED COB Strip Light for Customizable Lighting

1 / 5

Versatile RGB CCT Dimmable LED COB Strip Light for Customizable Lighting

Still deciding? Get samples of $ !

Order Sample

Send Inquiry

Product Description

📦 Basic Information

Model NO.	KCOB-12V480-P8WW
Product Name	Flexible Red/Green/Blue Color COB LED Strip DC24V
Voltage	12V/24V
Wattage	11W/M
Emitting Color	White
Color Temp	2700K, 3000K, 4000K, 6000K
LED Qty	384LEDs/M / 480LEDs/M
CRI (Ra>)	>90

IP Rating	IP20/IP65/IP67/IP68
Beam Angle	180 degree
PCB Material	Double-Sided Coated Pure Copper
PCB Color	White
Warranty	3-5 Years
Lifespan	50,000 Hours
Specification	5000*8mm/roll
Capacity	10,000m/Day

✨ Product Overview

Dimmable Dots-Free Light Flexible COB Strip

A revolutionary solution for linear lighting, achieving perfect dot-free effects without profiles or covers.

Continuous Linear Illumination: Uniform, soft, and elegant light with zero glare.
Flip-Chip Technology: Advanced packaging with 99.99% pure gold wire, ensuring no dead light risks.
High Thermal Dispersion: Small single-point current provides excellent heat dissipation and low decay.
Extreme Flexibility: Bending radius of only 5mm, allowing for any creative shape.
Versatile Applications: Ideal for furniture, KBB markets, or narrow corner installations.

🖼️ Product Showcase

🛠️ Installation Instructions

Use a power supply where the total strip power is approx. 80% of the rated capacity.
Recommended length is 5 meters/roll to maintain consistent brightness.
Ensure the surface is clean. Superior adhesive works best on glass, metal, and plastic.
Minimum bending diameter is 60mm to avoid damage to FPC components.
For outdoor use, ensure connectors are protected with waterproof silica gel.

🛡️ Reliability & Testing

Test Item	Conditions	Duration
Thermal Shock	-25ºC (15min) ↔ 100ºC (15min)	300 Cycles
Life Test	Ta = 25ºC	1000 Hours
High Humidity Storage	Ta = 85ºC, RH = 85%	1000 Hours

❓ Frequently Asked Questions

Q1: How do you ensure high quality? We maintain a 100% QC on-line and final inspection process. Our production follows ISO9001:2015 standards and all workers are strictly trained.

Q2: Can I get a sample for testing? Yes, we can supply free samples. Customers only need to cover the international express delivery charges.

Q3: Do you offer customization services? Yes, we provide professional custom designs for specific lighting requirements.

Q4: How long is the product warranty? We offer a 2-5 year warranty. If quality problems occur during this period, we will repair or replace the product for free.

Q5: What is the typical lead time? Sample orders take 3-5 days, small batches 10-15 days, and large orders are subject to negotiation.

Q6: How are the goods shipped? We usually ship via DHL, UPS, FedEx, or TNT, which typically takes 3-5 days to arrive. Sea and air freight are also available.
