📋 Basic Information
IP Rating
IP20/IP65/IP67/IP68
LEDs Material
99.99% Pure Gold Wire
PCB Material
Double-Sided Coated Copper
💡 Product Description
Cob 624 LEDs 12mm DC24V COB LED Strip Lights
A perfect solution for linear lighting with a Dot-Free effect. Continuous and uniform illumination provides soft, glare-free light using Flip-Chip technology to eliminate dead light risks.
⚙️ Key Features
- Dot-Free effect: Seamless linear lighting.
- High Flexibility: 5mm bending radius for creative designs.
- Durability: Long lifespan with excellent heat dispersion.
- Versatile: Ideal for furniture, cabinets, and architectural use.
| Item Type |
LED/m |
Volt |
W/m |
PCB Width |
Color |
CRI |
| RGBW COB | 560 | 24V | 16W | 10mm | RGBW | >90 |
| RGB COB | 768/840 | 12/24V | 14W/15W | 10mm | RGB | >90 |
| CCT COB | 608 | 24V | 14W | 10mm | CCT | >90 |
| White COB | 312/384/480 | 12/24V | 8W-14W | 5/8/10mm | 2700K-6000K | >90 |
📸 Detailed Photos
🏛️ Architectural Lighting Applications
- Architectural decorative lighting
- Archway, canopy, and bridge edge lighting
- Amusement park and theater mood lighting
- Emergency hallway and stairway accent lighting
- Backlighting for signage and channel letters
- Cove and edge-lit acrylic panel lighting
🛠️ Installation Guidelines
Power Supply: Use a power supply that handles 80% of the total strip power for stability.
Bending: Minimum bending diameter is 60mm to protect the PCB.
Mounting: 3M adhesive backing for glass, metal, and plastic. Clean surfaces before application.
📦 Packaging & Shipping
❓ Frequently Asked Questions
Q1: What is the advantage of COB LED strips compared to SMD?
COB (Chip on Board) strips provide a seamless, dot-free linear lighting effect without the need for additional diffusers, offering more uniform light distribution.
Q2: Can these LED strips be used outdoors?
Yes, we offer various waterproof ratings including IP65 (silicone coating), IP67 (silicone tube), and IP68 (full injection) for outdoor and underwater applications.
Q3: What is the standard warranty for these products?
Our COB LED strips come with a 3 to 5-year warranty, covering free repairs or replacements for quality-related issues.
Q4: Are the LED strips dimmable and color-adjustable?
Yes, we provide CCT (color temperature adjustable), RGB, RGBW, and addressable options that can be dimmed or color-controlled with compatible controllers.
Q5: How do I handle the voltage drop for long installations?
For lengths exceeding 5 meters, we recommend powering the strip from both ends or using custom voltage solutions to ensure consistent brightness.
Q6: What certifications do your products have?
Our products meet high-quality standards and carry CE and RoHS certifications, produced under ISO9001:2015 management systems.
